Product Description
Key Features:
- EdgeCore lifeline is made from Kevlar cables and a UV-resistant composite jacket, weighing 40% less than 3/16” galvanized cable used in most Class 2 SRL-P’s
- Compact design elevates the SRDs to align optimally with worker motion, increasing both comfort and productivity
- Features comprehensive fall clearance charts and tables inside the energy absorber cover
- Internal mechanism design minimizes unintentional lockups to keep you moving freely and productively
- Suitable for below D-ring tie-off up to five feet and leading edge exposures and hazards, including steel and precast concrete
- Rated for workers weighing up to 420 pounds, including clothes, tools, gear, etc.
- Features SpeedLink field replaceability of damaged retractable units, lowering overall cost of ownership and reducing equipment downtime
- Replacement retractable part number is 84108RP3
Specifications:
- Product Type: Self-Retracting Lifeline
- Lifeline: EdgeCore; 5,000 lb Minimum Static Strength
- Energy Absorber: Polyester Tear-Away
- Anchorage Connector: Plated Alloy Steel; 5,000 lb Minimum Static Strength with 3,600 lb Gate Strength
- Dorsal Connector: Aluminum Alloy; 3,600 lb Minimum
- Static Strength: 3,600 lb Minimum
- ANSI SRL Class/Type: Class 2 SRL-P
- Average Arrest Force: 1,350 lb Maximum
- Maximum Arrest Force: 1,800 lb
- Maximum Arrest Distance: 42"
- ANSI User Capacity: 130 to 310 lb Maximum
- OSHA User Capacity: 130 to 420 lb Maximum
Certifications:
- OSHA 1926.502 and 1910.66
- CSA Z259.2.2-2017
- ANSI Z359.14-2021 Class 2 SRL-P
